hansgrohe Rainfinity
Showerpipe 250 1jet EcoSmart with ShowerTablet 350

Showerpipe 250 1jet EcoSmart with ShowerTablet 350
 View in AR
 360° view
Change variant
hansgrohe Rainfinity
Select variant
Showerpipe 250 1jet EcoSmart with ShowerTablet 350
Showerpipe 360 1jet with ShowerTablet 350
Finish Chrome

Model no. 28742000

Article features

  • consists of: overhead shower, hand shower, shower thermostat, shower hose, slider, shower bar
  • overhead shower Rainfinity 250 1jet
  • shower head size overhead shower: 250 mm
  • spray type overhead shower: PowderRain
  • spray disc surface: graphite
  • surface shelf: anodized aluminium
  • function from: 6 l/min
  • spray type hand shower: PowderRain, Intense PowderRain, MonoRain
  • maximum flow rate of hand shower at 3 bar: 8,2 l/min
  • maximum flow rate for Showerpipe at 3 bar: 8,2 l/min
  • minimum flow pressure: 1,6 bar
  • max. operating pressure: 10 bar
  • ball-joint: overhead shower angle adjustable
  • 90° position adjustable slider, pivots left and right, up and down
  • CoolContact thermostat: Prevents the housing from heating up, making showering even safer
  • thermostat ShowerTablet 350
  • material front of thermostat and pipe: safety glass
  • SafetyStop at 40°C
  • adjustable hot water limitation
  • outlets controlled via turning handle
  • will not run two functions at same time
  • suitable for continuous flow water heaters
  • mounting type: exposed installation
  • connection dimension: DN15
  • connection thread: G ½
  • centre distance: 150 ± 12 mm
  • intrinsically safe against backflow
  • bar width: 61 mm
  • 2 functions
  • BE BelgAqua,GB TMV2,TH TISI,NL KIWA,GB Reg4,DE 1+Konformität,DE P-IX,FR ACS,MY SPAN,SE STA,PL PZH,GB WRAS

Downloads

Installation information

Installation example

Download all files

Innovative technologies

Safe and indulgent showering

Thermostatic mixer with innovative cooling technology to prevent scalding and unpleasant touching.

Want to save water? With pleasure!

Shower that only uses 8 l/min and thus reduces water thanks to a flow limiter. Eco-friendly and wallet-friendly.

Want to save water? With pleasure!

Shower that only uses 8 l/min and thus reduces water thanks to a flow limiter. Eco-friendly and wallet-friendly
Want to save water? With pleasure!

Less limescale, more joy

Limescale deposits and dirt can be simply rubbed off using a finger, creating less of a need to clean.

Great showering pleasure

Large-scale distribution of the water in the shower so that the whole body is cocooned in feel-good droplets.

Always constant water temperature

Thermostat with integrated temperature control for constant water temperature.
Always constant water temperature

For mindful use of water

Actively regulates water consumption – the amount of water can be adjusted via the control dial.
For mindful use of water

Safety lock at over 40 °C

Safety lock at over 40 °C - temperature limit, which prevents excessively hot water from escaping.
Safety lock at over 40 °C

Intuitive jet adjustment

A playful way to control the water flow, shower or spray type at the simple touch of a button.

CoolContact

Safe and indulgent showering

Thermostatic mixer with innovative cooling technology to prevent scalding and unpleasant touching.

EcoSmart

Want to save water? With pleasure!

Shower that only uses 8 l/min and thus reduces water thanks to a flow limiter. Eco-friendly and wallet-friendly.

EcoRight

Want to save water? With pleasure!

Shower that only uses 8 l/min and thus reduces water thanks to a flow limiter. Eco-friendly and wallet-friendly

QuickClean

Less limescale, more joy

Limescale deposits and dirt can be simply rubbed off using a finger, creating less of a need to clean.

XXL Performance

Great showering pleasure

Large-scale distribution of the water in the shower so that the whole body is cocooned in feel-good droplets.

Thermostat

Always constant water temperature

Thermostat with integrated temperature control for constant water temperature.

Water flow control

For mindful use of water

Actively regulates water consumption – the amount of water can be adjusted via the control dial.

SafetyStop

Safety lock at over 40 °C

Safety lock at over 40 °C - temperature limit, which prevents excessively hot water from escaping.

Spray Types

Relaxing, micro-fine droplets that gently and quietly envelop the body. The water is transformed into a delicate cocoon that sensually embraces the body. For sensual showering and indulgent, deep relaxation.

PowderRain

Relaxing, micro-fine droplets that gently and quietly envelop the body. The water is transformed into a delicate cocoon that sensually embraces the body. For sensual showering and indulgent, deep relaxation.

Awards

iF product design award 2024

iF product design award 2024

 Everything from cars to toothbrushes: products that receive this award rank among the best-designed products in the world. Globally recognised seal of quality, awarded by the International Forum Design since 1953.

Five-year manufacturer’s guarantee

5

year manufacturer's guarantee

Always creating the highest quality products defines our approach to design, manufacturing and performance. ‘Made by Hansgrohe’ is your assurance of quality.
We endeavour to always provide up-to-date, complete information on our website. However, we do not assume any liability for the suitability of the information for particular uses.
