hansgrohe Raindance Rainmaker
Overhead shower 680/460 3jet with lighting

Overhead shower 680/460 3jet with lighting
 View in AR
 360° view

Model no. 28418000

Article features

  • shower head size: 680 x 460 mm
  • spray type: RainAir, Whirl, RainAir XL
  • flow rate RainAir spray at 3 bar: 20 l/min
  • flow rate RainAir XL at 3 bar: 28,1 l/min
  • flow rate WhirlAir spray at 3 bar: 22 l/min
  • function from: 19 l/min
  • maximum flow rate at 3 bar: 28,1 l/min
  • minimum flow pressure: 3 bar
  • material spray disc: metal
  • the 3 spray zones must be controlled via 3 valves or a diverter valve with 3 outlets
  • installation: ceiling mointed
  • connection thread: G ½
  • connection dimension: DN20
  • connection type: basic set
  • with integrated lighting
  • illuminant: LED
  • power supply: 12 V DC
  • transformer power supply for concealed installation 12 V, 18 W
  • input voltage: 100 - 240 V AC / 50 / 60 Hz
  • output voltage: 12 V DC
  • colour temperature: 2700 K
  • energy efficiency class: contains light sources of energy efficiency class G
  • not suitable for continuous flow water heaters

Downloads

Installation information

Scale drawing

Installation example

Download all files

Information

Please always observe the safety and installation information for your product. You find these details within the assembly instructions.
Information
Please note that other products are required to install the product.

Required parts

Basic set for overhead shower 680/460 3jet
hansgrohe Raindance Rainmaker

Basic set for overhead shower 680/460 3jet

Innovative technologies

More pleasure, more efficiency

Mixes generous quantities of air into the water to create light, pearl-like droplets that caress the skin. The shower feels luxurious, even though little water is consumed. The spray causes less splash, reducing the time to clean the shower area.

Less limescale, more joy

Who actually likes cleaning? Limescale deposits and dirt disappear in an instant with this technology. Simply rub the flexible silicone discs or nozzles with a finger. It’s fast and keeps cleaning to a minimum.

Great showering pleasure

XXL showering indulgence that envelops the complete body in real-life dreams of water using wonderfully soothing spray types from hand showers and overhead showers with diameters of 100 to 600 mm.

AirPower

More pleasure, more efficiency

Mixes generous quantities of air into the water to create light, pearl-like droplets that caress the skin. The shower feels luxurious, even though little water is consumed. The spray causes less splash, reducing the time to clean the shower area.

QuickClean

Less limescale, more joy

Who actually likes cleaning? Limescale deposits and dirt disappear in an instant with this technology. Simply rub the flexible silicone discs or nozzles with a finger. It’s fast and keeps cleaning to a minimum.

XXL Performance

Great showering pleasure

XXL showering indulgence that envelops the complete body in real-life dreams of water using wonderfully soothing spray types from hand showers and overhead showers with diameters of 100 to 600 mm.

Spray Types

Gentle, air-enriched droplets deliver a soft and soothing shower sensation. The generous rain feels pleasant across the skin while remaining efficient, rinsing shampoo thoroughly for a refreshing and indulgent experience.
Gentle droplets enriched with air from the luxurious shower rain feel silky soft on the skin for an indulgent shower. Additionally, this spray type is efficient and thorough enough to rinse out shampoo.
Rotating water sprays to pleasantly shower away everyday tensions. Individual sprays of water flow around each other in a helical pattern, helping to relieve tension with their gentle massaging action.

RainAir

Gentle, air-enriched droplets deliver a soft and soothing shower sensation. The generous rain feels pleasant across the skin while remaining efficient, rinsing shampoo thoroughly for a refreshing and indulgent experience.

RainAir XL

Gentle droplets enriched with air from the luxurious shower rain feel silky soft on the skin for an indulgent shower. Additionally, this spray type is efficient and thorough enough to rinse out shampoo.

Whirl

Rotating water sprays to pleasantly shower away everyday tensions. Individual sprays of water flow around each other in a helical pattern, helping to relieve tension with their gentle massaging action.

Five-year manufacturer’s guarantee

5

year manufacturer's guarantee

Always creating the highest quality products defines our approach to design, manufacturing and performance. ‘Made by Hansgrohe’ is your assurance of quality.
We endeavour to always provide up-to-date, complete information on our website. However, we do not assume any liability for the suitability of the information for particular uses.
